Strong pulling force Neodymium Pot NdFeB Magnet countersunk magnet N35 round base magnet with internal thread

Contact Now
Hangzhou Yangyi Magnetics Co., Ltd.
City:hangzhou
Province/State:zhejiang
Country/Region:china
Contact Person:MsMaggie Yu
Contact Now

Strong pulling force Neodymium Pot NdFeB Magnet countersunk magnet N35 round base magnet with internal thread

Ask Latest Price
Video Channel
Brand Name :YYMAG
Model Number :A-series
Certification :ISO,SGS,REACH
Place of Origin :ZHEJIANG PROVINCE,CHINA
MOQ :10pcs
Price :US$0.5-US$10 Per Piece
Payment Terms :T/T, Western Union, MoneyGram,Paypal
Supply Ability :100000 per month
Delivery Time :15days
Packaging Details :Standard Exporting Packing, Magnets+ Small Carton+ Green Foam + Big Carton, Carton Size: 33x24x15cm
Materials :NdFeB Magnet
Grade :N35-N52(M,H,SH,UH,EH)
Working Temperature :80-200 Degree Centigrade
Tolerance :+/-0.1mm
Coating :NI-CU-NI
Application :for holding
Size :can be customized
Processing Service :Bending, Welding, Decoiling, Cutting, Punching, Moulding
Color :silver
more
Contact Now

Add to Cart

Find Similar Videos
View Product Description
Pot magnets
Strong pulling force Neodymium Pot NdFeB Magnet countersunk magnet N35 round base magnet with internal thread

Neodymium magnet,the third generation of rare-earth permanent magnet,is the most powerful and advanced permanent magnet today.Ndfeb is named as “Magnet King”for its high remanence,high energy.Moreover,it has the high performance and high cost ration, because of the rich rare earth resources in China and the ever-changing production process and technological progress.It can be easily formed into various sizes and different shapes ,such as disc. segment.ring,block and etc.

Steel cover. Nickel coated pot magnet (NdFeB), with internal thread.

Strong pulling force Neodymium Pot NdFeB Magnet countersunk magnet N35 round base magnet with internal threadStrong pulling force Neodymium Pot NdFeB Magnet countersunk magnet N35 round base magnet with internal thread
Product Name
Strong pulling force Neodymium Pot NdFeB Magnet countersunk magnet N35 round base magnet with internal thread
Material
Neodymium magnet ( NdFeB )
Shape
Round,Disc, Cylinder, Ring,Block, Rectangular, Countersunk,Bar,Hook, cup, Trapezoid, Irregular shapes , accept customized
Coating
Nickel, Zinc, Chromium, Epoxy, Gold, Silver, Parylene, Everlube, Passivation, Copper, Chemical, PTFE and more
Magnetic direction
Magnets are sunken in to a steel plate. The north pole is on the center of the magnetic face and the south pole is on the outer
edge around it.
Vertical pull force
From 80kg to 3000kg
Testing method
The value of the magnetic pull force has some thing to do with the thickness of the steel plate and pull speed. Our testing value
is based on the thickness of the steel plate =10mm, and pull speed = 80mm/min.) Thus, different application will have different
result.
Size tolerance
±0.05mm for diamater /thickness, ±0.1mm for width/ length
Grade of Magnets
N35-N52; N35M-N50M; N35H-N48H; N33SH-N48SH;N30UH-N40UH; N28EH-N38EH;N28AH-N35AH
Applications
Neodymium(NdFeB) Magnet are widely used in many fields, such as motors,sensors, microphones, wind turbines, wind generators,
printer, switchboard,packing box , loudspeakers, magnetic separation, magnetic hooks, magnetic holder, magnetic chuck, ect.
Product Show
Strong pulling force Neodymium Pot NdFeB Magnet countersunk magnet N35 round base magnet with internal thread
Strong pulling force Neodymium Pot NdFeB Magnet countersunk magnet N35 round base magnet with internal thread
Packing

As the magnets have strong attraction and we will use the spacer to apart the magnets each other in case people will be hurt when take it out. Then, they will be packed in a white box of pieces each, several boxes to a carton.

+By Air: If the goods will be shipped by air, all the magnetic should be degaussed and we will use Iron sheet to shield.
+By Sea: If the goods are will be shipped by sea, we will place a pallet on the bottom of cartons.

Shipping

Express (TNT, DHL, FedEx, UPS, etc), Air, Ocean.
A: The weight is under 40Kgs, we recommend to send them in shielding boxes to you by Express.
B: The weight is between 40Kgs-100Kgs, it can be sent by Express or Air.
C: The weight is over 100Kgs, we recommend to send them by Ocean.
